Dimension |
Unit |
QY50K-Ⅱ |
|---|---|---|
|
Overall length |
mm |
13 750 |
|
Overall width |
mm |
2800 |
|
Overall height |
mm |
3 520 |
|
Weight |
|
|
|
Total weight in travel |
kg |
41 000 |
|
Front axle load |
kg |
15 000 |
|
Rear axle load |
kg |
26 000 |
|
Power |
|
|
|
Engine model |
|
WD615.334(domestic III) |
|
Engine rated power |
kW/(r/min) |
247/2200 |
|
Engine rated torque |
N.m/(r/min) |
1350/1400 |
|
Travel |
|
|
|
Max. travel speed |
km/h |
80 |
|
Min. turning diameter |
m |
24 |
|
Min. ground clearance |
mm |
291 |
|
Approach angle |
° |
17 |
|
Departure angle |
° |
11 |
|
Max. grade ability |
% |
40 |
|
Fuel consumption for 100km |
L |
45 |
|
Main performance |
|
|
|
Max. rated total lifting capacity |
t |
50 |
|
Min. rated working radius |
m |
3 |
|
Turning radius at turntable tail |
m |
3.482 |
|
Max. lifting torque |
kN.m |
1764 |
|
Base boom |
m |
11.3 |
|
Fully extended boom |
m |
42.7 |
|
Fully extended boom+ jib |
m |
57.7 |
|
Longitudinal outrigger span |
m |
5.91 |
|
Lateral outrigger span |
m |
6.9 |
|
Working speed |
|
|
|
Boom luffing time |
s |
88 |
|
Boom full extension time |
s |
180 |
|
Max. swing speed |
r/min |
≥2.0 |
|
Max. speed of main winch (single rope) (no load) |
m/min |
≥110 |
|
Max. speed of aux. winch (single rope) (no load) |
m/min |
≥110 |
